Filter chamber is composed by two filter plates. Under the pressure of feeding pump, suspension is pumped into each filter chamber, solid are stopped in filter chamber to form residue, while filtrate passes through filter cloth and flow along the filter plate trench to discharge channel. Solid is separated from liquid. When filtration is complete, washing water can be introduced to wash residue. After washing, compressed air can be introduced to blow remaining washing liquid out. Open filter plate and discharge cakes (cakes are stored in filter chamber between the two filter plates), clean filter cloth, and re-pressing plate to start the next working cycle.
1. Big pressing force(17-20MPa) can avoid leakage effectively.
2. Hydraulic station adopts international famous motor, it is steady in operation.
3. Auto closing and auto opening.
4. Labor saving.
5. It specially apply to models with large capacity, it can ensure good filtering effect.
Filter chamber is composed by two filter plates. Under the pressure of feeding pump, suspension is pumped into each filter chamber, solid are stopped in filter chamber to form residue, while filtrate passes through filter cloth and flow along the filter plate trench to discharge channel. Solid is separated from liquid. When filtration is complete, washing water can be introduced to wash residue. After washing, compressed air can be introduced to blow remaining washing liquid out. Open filter plate and discharge cakes (cakes are stored in filter chamber between the two filter plates), clean filter cloth, and re-pressing plate to start the next working cycle.
Chemical, petroleum, pharmaceutical, light industry, food, mineral processing, water treatment, electroplating, metallurgy, dyes, textile,etc.
